Leet Code 84. Largest Rectangle in Histogram — Graphically Explained Python3 Solution
Problem Description
Given n non-negative integers representing the histogram’s bar height where the width of each bar is 1, find the area of largest rectangle in the histogram.
Above is a histogram where width of each bar is 1, given height = [2,1,5,6,2,3].
The largest rectangle is shown in the shaded area, which has area = 10 unit.
Example:
Input: [2,1,5,6,2,3]
Output: 10Solution
Obvious Solution
The obvious (and brute force) way is to use 2 pointers: left and right. Let left points to index 0 ~ N-1 and then right to left and N-1. For each left and right pair, I can calculate the area[left, right] using (right-left+1) * min(heights[left], heights[left+1],heights[left+2],…,heights[right]). Its time complexity is at least be O(N²).
Best Solution (to me)
[Credit] This is described by @TravellingSalesman in disucssion area (https://leetcode.com/problems/largest-rectangle-in-histogram/solution/) and here I just try to illustrate it further.
Take the example of heights array [2,1,5,6,2,3], each area must be in the height of any element within heights. In other words, the maximum area will either be an area with height=2, or an area with height=1, or an area with height=5 and etc. So instead of using 2 pointers like mentioned in above section, here I can use height central perspective: if I want to use heights[2] (=5) as the height of a candidate area, how to get its width? Not surprisingly, I need to look to its left to find the first (leftmost) height (its index referenced as L in following) that is smaller than 5 and rightmost height (its indexreferenced as R in following) that is smaller than 5: yellow arrows in below graph (Pic 1) illustrate the boundaries. With that the width=(R-L)-1=4–1–1=2 and hence the area = width * height = 2 * 5 = 10 (as shown in yellow rectangle).
What if a height is the samllest one so there is no valid L, R? For example, for heights[1]=1, obviously the area of heights[1]=1 will has the width=6 (the length of the heights array). Logically, I can assume L = -1 while R=size-of-heights. Similar logic applies to an element that seems has only a valid L or R: for example, red rectangle indicates an area with the heights[5] and it’s L=4 and R=6 so its width=R-L-1=6–4–1=1 and its area = 1 * 3=3.
There is a smat way to implement above algorithm: using a stack that stores ascending elements. When I iterate the array, if the top of the stack (as referenced as stack[-1] in Python) is larger than current element, for the one on the top of the stack, we actually find its R; its L is actually the second to the top: with this, I can conclude the area with the height corresponding to the top of the stack; if the top of the stack (as referenced as stack[-1] in Python) is smaller or equal than current element, that means I still don’t know what’s the R for current top element in the stack, so I will just push current element to the stack.
Sounds dizzy? Let me walk through the algorithm with the example [2,1,5,6,2,3]. To simplify writing, I use Area[i] to denote the area whose height is height[i].
0, first I run into index=0 (height=2). It’s the first one and I know its L = -1 but am not sure the value of R, so I just put its index (so that later I can get its index for width calculation and in the same time get its value for height through heights[index]) in the stack. Now stack=[0].
1, now I come to index=1(height=1). It’s less than current top of stack’s value since heights[1] < heights[stack[-1]]. So I find heights[stack[-1]] (aka heights[0])’s R= current index. So for the area of heights[0] (illustrated by green vertical lines in Pic 1) is (R-L-1) * heights[0] = (1-(-1)-1)*2=2. So I have Area[0] calculated. I will pop up index 0 from stack since its area is calcuated; but for index 1, its corresponding area is not yet calculated (I don’t know its R although its L is -1), so I push it to stack and now stack=[1].
2, now I come to index=2(height=5). Since heights[2] > heights[stack[-1]], for stack[-1], I cannot decide its R, just push current index to stack and makes stack=[1,2].
3, now I come to index=3(height=6). Same as #2 and now stack=[1,2,3].
4,now I come to index=4(height=2). Now heights[4] <heights[stack[-1]], it means for index stack[-1] (aka index 3), I find its R and therefore Area[3]= (R-L-1)*heights[3]=(4-heights[stack[-2])*heights[3]=(4–2–1)*6=6. Now I pop up the top of the stack and the stack=[1,2]. Notice stack[-1]=2 and heights[2] >heights[4], it indicates heights[2]’s R=4 as well. So similarly I can have Area[2]= (R-L-1)*heights[2]=(4-heights[stack[-2])*heights[3]=(4–1–1)*5=10 and pop up the stack to get stack=[1]. Now stack[-1]=1 and heights[1] < heights[4] so heights[1]’s R is not yet decided and hence it stays at the stack. Now stack=[1,4].
5,now I come to index=5(height=3) and similar to #3 now stack=[1,4,5].
6, now I go beyond the array. Remember there is a default R=size-of-array=6? So for everyone remaining in the stack, its R is the index after it (except for the last one, it’s 6) and its L is the index before it(except for the first one, it’s -1). Bear in mind that heights array is [2,1,5,6,2,3] and I will have
Area[5]= (6–4–1) * height[5] = 3
Area[4]=(6–1–1) * height[4] = 8
Area[1]=(6-(-1)-1)* height[1] = 6
7, looking at Area[x] where x in 0~5, the largest one will be the answer.
Source Code
Slightly different from above walk-through, I add a “-1” to the stack in the beginning (serving as default L). In the end, an extra checking (corresponding to #6 in above) is performed.
Time & Space Complexity
As illustrated above, I only need to travse the heights array once and when visiting an element, although there is a need to do while loop against the stack, each element will just be inside the stack for once. Therefore, the time complexity is O(N) and so is space complexity.
