Leet Code 490. The Maze — Graphical Explained Python3 Solution

Photo by Susan Yin on Unsplash

Problem Description

There is a ball in a maze with empty spaces and walls. The ball can go through empty spaces by rolling up, down, left or right, but it won’t stop rolling until hitting a wall. When the ball stops, it could choose the next direction.

Given the ball’s start position, the destination and the maze, determine whether the ball could stop at the destination.

The maze is represented by a binary 2D array. 1 means the wall and 0 means the empty space. You may assume that the borders of the maze are all walls. The start and destination coordinates are represented by row and column indexes.

Example 1:

Input 1: a maze represented by a 2D array

0 0 1 0 0
0 0 0 0 0
0 0 0 1 0
1 1 0 1 1
0 0 0 0 0

Input 2: start coordinate (rowStart, colStart) = (0, 4)
Input 3: destination coordinate (rowDest, colDest) = (4, 4)

Output: true

Explanation: One possible way is : left -> down -> left -> down -> right -> down -> right.

Solution

This is a typical tree like problem which DFS/BFS can solve.

From a specific point (in the beginning it’s the Start), I have at most 4 directions to roll a ball; in each direction, the ball will stop when it hits a wall and that stop will become a start point to roll. If the stop matches the Destination, then that means I can reach the Destination from Start.

Additional favor the problem adds is rolling. The rolling, in Python3 implementation, means keep changing either X or Y coordinate consistently in the same manner.

A very common technique is to use a dirs variable (which contains the shift in each coordinate for each direction) and the corresponding rolling/stop mechanism is illustrated as below.

dirs = [(-1,0), (1,0), (0,-1), (0,1)]

pos = (startX, startY)
for d in dirs:
  newX = pos[0]
  newY = pos[1]
  while(True): #rolling
    possibleNewX = newX + d[0]
    possibleNewY = newY + d[1]
    if (possibleNewX >= 0 and possibleNewX < len(maze) ) and (possibleNewY >= 0 and possibleNewY < len(maze[0])) and (maze[possibleNewX][possibleNewY] != 1):
      #rolling to newX and newY and may continue rolling
      newX = possibleNewX
      newY = possibleNewY
      continue
    else: #either hit wall or surrounding frames
      break
  newStop = (newX, newY)

Complete solution is available in below (please refer to following section Python 3 knowledge points where I introduce the framework of DFS Python3 implementation that can help to understand codes in following block).

Time & Space Complexity

Assuming the maze is M*N, actually I need to touch nearly every cell (except walls), the time spent is directly related to the scale of M*N. Therefore, the time complexity is O(M*N).

I use a visited list to store all stop positions the algorithm will run into. Also, since I use recursive calls of rollFrom(), each time execution stack will used when a call is invoked. Actually both are related since normally a stop will lead to 4 rollFrom() so space complexity is directly related to the number of stops. In a M*N maze, the stop number is also directly scaling along with the size, so space complexity is also O(M*N).

Python 3 knowledge points

This is a typical problem which can be solved by either DFS and BFS (in same time complexity). I have an evolving post which contains templates for common algorithms include DFS and BFS. Below contents are extracted from that post.

1. Typical DFS Python3 template

#params are normally those will change in each round of dfs
#for example, a position that something inside dfs will start with
#I'd suggest a more meaningful name to use than "dfs"
#like rollFrom(postion)

visited = []

def dfs(current_node):
  #processing current_node to generate more leads(nodes)
  nodes = processing of current_node
  visited.append(current_node)

  for node in nodes:
    if node not in visited:
      dfs(params_turning_from_branch_info)

dfs(start_node) #kick start dfs

Above template will check each path one by one, but sometimes I will need to abort the checking if an answer is found in some path. In that case, the template can be slightly modified to be:

#params are normally those will change in each round of dfs
#for example, a position that something inside dfs will start with
#I'd suggest a more meaningful name to use than "dfs"
#like rollFrom(postion)

visited = []

def dfs(current_node):
  #processing current_node to generate more leads(nodes)
  nodes = processing of current_node
  visited.append(current_node)

  #during above processing, some required criteria are met
  if(criteria are met):
    return True
  for node in nodes:
    if node not in visited:
      if dfs(node):
        return True
  return False

return dfs(start_node) #kick start dfs

2. Typical BFS Python3 template
Similarly to DFS, I may use BFS to find ALL possible answers (which means I need to navigate all nodes). Also, I may just stop by the first answer, which below template applies to.

Also, below template is not using recursive calls.

visited = []
toVisit = [start_node]

while(len(toVisit) > 0):
  toVisitInNextLayer = []

  for current_node in toVisit:
    #processing node to generate more leads(nodes)
    nodes = processing of current_node
    visited.append(current_node)

    #during above processing, some required criteria are met
    if(criteria are met):
      return True

    for node in nodes:
      if node not in visited:
        toVisitInNextLayer.append(node)

  toVisit = toVisitInNextLayer

return False
